Plastic Dynamic Silencer - SPD
Fill out the form to request information and quote.
Unit of measurement expressed in millimeters.
Dynamic Self-cleaning plastic silencer
Unit of measurement expressed in millimeters.
| Code | Item | A | Diam | B | C | D | E | H | Ch |
| 168 | SPD 1/8 | 1/8" | 7,0 | 2,5 | 15,5 | 7,0 | 25,5 | 35,0 | 10,0 |
| 169 | SPD 1/4 | 1/4" | 9,0 | 3,0 | 19,5 | 7,0 | 32,0 | 43,0 | 12,0 |
| 170 | SPD 3/8 | 3/8" | 12,0 | 3,0 | 24,5 | 11,0 | 45,0 | 59,0 | 16,0 |
| 171 | SPD 1/2 | 1/2" | 12,0 | 3,0 | 24,5 | 11,0 | 45,0 | 59,0 | 16,0 |
| 172 | SPD 3/4 | 3/4" | 20,0 | 10,0 | 50,0 | 18,0 | 90,0 | 118,0 | 25,0 |
| 173 | SPD 1 | 1" | 20,0 | 10,0 | 50,0 | 18,0 | 90,0 | 118,0 | 25,0 |
| noise level in dB 6 BAR | ||||||
| 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | |
| 87 | 84 | 90 | 90 | 91 | 90 | |
| noise level in dB 4 BAR | ||||||
| 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | |
| 84 | 81 | 83 | 83 | 85 | 85 | |
Flow Tests
